Description
2023 CAT 289D3 Skid Steer
This 2023 CAT 289D3 is in great condition and ready to work. With only 2,862 hours (still in use), it’s been well maintained and runs strong. The tracks are like new, offering excellent traction and stability. While it doesn’t have A/C, everything else is in top working order — smooth controls, strong hydraulics, and that reliable CAT power you expect.
It offers a maximum lift height of 10 ft 4 in, perfect for loading trucks with ease and efficiency.
A clean, solid machine that’s been well cared for and performs beautifully on the job.
Caterpillar 289D3 Compact Track Loader — 2023 Model
Manufacturer: Caterpillar Inc.
Model: 289D3
Year: 2023
Type: Compact Track Loader
Lift Design: Vertical Lift
Operating Weight: 10,688 lb (4,850 kg)
Rated Operating Capacity (50% of Tipping Load): 3,450 lb (1,565 kg)
Tipping Load: 6,900 lb (3,130 kg)
Breakout Force (Bucket): 7,538 lb (3,419 kg)
Ground Pressure (Standard Tracks): 5.7 psi (39.3 kPa)
Engine
Engine Model: Cat C3.3B DIT (Turbocharged)
Gross Power: 74.3 HP (55.4 kW)
Net Power (SAE J1349): 72.9 HP (54.4 kW)
Displacement: 203 in³ (3.33 L)
Cylinders: 4
Cooling System: Liquid
Fuel: Diesel
Emissions: U.S. EPA Tier 4 Final / EU Stage V
Performance
Travel Speed (Standard): 5.9 mph (9.5 km/h)
Travel Speed (Two-Speed Option): 8.4 mph (13.6 km/h)
Hydraulic System Pressure: 3,335 psi (23,000 kPa)
Hydraulic Flow (Standard): 23 gal/min (87 L/min)
Hydraulic Flow (High Flow Option): 30 gal/min (114 L/min)
Maximum Lift Height to Bucket Pin: 10 ft 4 in (3.15 m)
Dump Angle at Maximum Height: 52°
Rollback Angle at Ground Level: 30°
Dimensions
Length with Bucket on Ground: 146.2 in (3,714 mm)
Width (over Tracks): 78 in (1,981 mm)
Height to Top of Cab: 83.1 in (2,111 mm)
Ground Clearance: 8.9 in (226 mm)
Turning Radius (from Center — Machine Rear): 58.9 in (1,497 mm)
Track System
Track Width: 17.7 in (450 mm)
Track on Ground Length: 64.2 in (1,630 mm)
Track Condition: Like new
Cab & Features
Cab Type: Enclosed ROPS / FOPS
Air Conditioning: No A/C
Joystick Controls: Standard ISO control pattern
Seat: Suspension seat
Display: Advanced Display with backup camera (optional)
Auxiliary Hydraulics: Standard and High Flow available
Up for sale is a strong running 2023 Caterpillar 289D3. Bank repo unit. Previous owner couldn't keep up with financing. Preventative maintenance was done religiously every 500 hours.
It has been inspected and maintained. Recent service includes: Battery and alternator replaced last season.
Priced competitively for a quick turnaround.
Specifications
| Manufacturer | Caterpillar |
| Model | 289D3 |
| Year | 2023 |
| Condition | Used |
| Stock Number | BAM-1045 |
| Hours | 2862 |
| Transmission | Hydrostatic / Powershift |
| Engine | Tier 4 Final Diesel |
| Operating Weight | ~13931 lbs |
| Reach / Dig Depth | standard configuration |
| Tires | Pneumatic, ~70% tread remaining |
| Cab | Enclosed ROPS with A/C & Heat |
| Auxiliary Hydraulics | Plumbed |
| Controls | Pilot Joystick Controls |
